Description:

Features:

• Powerful 369cc Ariens AX369 Engine
• Designed to function in sub-zero conditions
• 120-volt electric start w/recoil (cord not included)
• Throws snow from 3 ft. up to 50 ft.
• Heavy Duty Disc-O-Matic Drive With Large Cast Iron Gear Case
• Easily shift into any of the six forward or two reverse speeds
• Provides additional power in extreme snow conditions
• Auto-Turn Steering Technology
• Senses change in direction automatically as you turn
• Adjusts power to the inside wheel to make turning easier
• Handwarmers
• Keeps your fingertips toasty warm in sub-zero weather
• Quick Turn Chute Rotates Up To 200 Degrees
• Single lever adjusts direction and height of snow stream
• Remote Chute Deflector Control
• Dash-mounted control to change position & angle of the deflector
• Interlocking Controls
• Locks both handles, freeing one hand for chute operation
• 16" x 4.8" Directional Tread Tires
• Virtually eliminates the need for tire chains

Specifications:

Engine

• Brand: Ariens
• Type: 4-Cycle OHV
• Displacement: 369 cc
• Starting System: 120-Volt Electric Start with Recoil Backup
• Fuel Tank Capacity: 3.8 gallons
• Torque: 17 lbs

Auger Housing & Chute Control

• Stage Type: Two-Stage
• Auger Diameter: 14 inches
• Impeller Diameter: 14 inches
• Impeller Profile: Steel 3-Blade
• Auger Material: Serrated Steel
• Chute Material: Steel
• Chute Rotation: Quick-Turn
• Turning Radius: 200 degrees
• Maximum Throwing Distance: 50 feet
• Clearing Width: 30 inches
• Intake Height: 21 inches

Drive System

• Drive Type: Disc-O-Matic
• Steering: Auto-Turn
• Gear Case: Cast Iron
• Forward Speeds: 6
• Reverse Speeds: 2
• Tires: 16" x 4.8" Directional Snow Tread

Features & Options

• Drift Cutters: Sold Separately
• Front Weights: Sold Separately
• Hand Warmers: Yes
• Headlight Type: Halogen
• Interlocking Controls: Yes
• Remote Deflector Controls: Yes
• Skid Shoes: Included – Reversible

Dimensions & Warranty

• Weight: 270 lbs
• Product Length: 57.91 in
• Product Width: 32.4 in
• Product Height: 44.25 in
• Consumer Warranty: 3 Years
• Commercial Warranty: 90 Days
