Description:

You’ll ride with pride as you deliver that perfect Gravely cut on the Z-Stance. This powerful commercial stand-on mower is easy to maneuver and a breeze to maintain. It’s three deck sizes make quick work of a corporate campus or a gated backyard. You take a stand for comfort, ingenuity, and durability when you’re on a Z-Stance.

Specifications:

Engine

• Brand/Model: Kawasaki® FS651V
• Horsepower: 22 hp
• Displacement: 44.3 cu in / 725.9 cc
• Fuel Type: Gas
• Fuel Capacity: 4.5 gal / 17 L

Drive System

• Type: Hydrostatic
• Transmission: Hydro-Gear® ZT-3100® Transaxles
• Brake: Lever-activated parking brake
• Driver Position: Stand-on
• Forward Speed: 7 mph / 11.3 kph
• Reverse Speed: 3 mph / 4.8 kph

Wheels

• Front Wheels: 11 x 6 in - 5 in
• Rear Wheels: 20 x 10 in - 8 in
• Front Wheel Track: 38.5 in
• Rear Wheel Track: 46.2 in / 117.3 cm

Electric

• Charger: Standard
• Battery Capacity: 300 CCA
• Battery: 12V, U1, Lead Acid (Maintenance Free)
• Number of Batteries: 1

Deck

• Size / Cutting Width: 52 in / 132.1 cm
• Deck Type: Fabricated X-Factor® 3
• Material: 10-gauge steel
• Spindles: Mechanical
• Discharge: Side
• Cutting Height Range: 1.5 – 5 in (3.8 – 12.7 cm)
• Coverage Rate: 3.6 acres per hour / 1.5 hectares per hour

Dimensions

• Weight: 763 lb
• Length: 65.5 in / 166.4 cm
• Width (Deck Only): 52 in / 132.1 cm
• Width (Chute Up): 55 in / 139.7 cm
• Width (Chute Down): 66.8 in / 169.5 cm
